903 Compact Wheel Loader

903 Compact Wheel Loader

360° Exterior View

The Cat® 903 is compact, yet powerful, delivering high performance with outstanding versatility. The all new C1.7 engine provides better all-around performance. Features such as engine and ground speed control, ...
PDF Print Share

Engine

Maximum Gross Power
48HP
Engine Model
Cat C1.7*
Net Power @ 2,200 rpm - SAE J1349:2011
45HP
Net Power @ 2,200 rpm - ISO 9249:2007
45HP
Bore
3.3in
Stroke
3.9in
Displacement
104in²
Note (1)
Advertised power is tested per the specified standard in effect at the time of manufacture.
Note (2)
Net power advertised is the power available at the flywheel.
Note
*Engine meets U.S. EPA Tier 4 Final emission standards.

Weights

Operating Weight
9200lb

Buckets

Bucket Capacities
0.6-1.0 m3 (0.8-1.3 yd3)
Bucket Capacities - General Purpose
0.6 m3 (0.8 yd3)
Bucket Capacities - Light Material
1.0 m3 (1.3 yd3)

Transmission

Travel Speed
12.4mile/h

Hydraulic System

Main Relief
3336psi
3rd Auxiliary Flow
14.1gal/min
Hydraulic Cycle Time - Lift
4.5s
Hydraulic Cycle Time - Dump
0.7s
Hydraulic Cycle Time - Lower, Float
2.3s

Cab

ROPS
ISO 3471:2008
FOPS
ISO 3449:2005 Level II

Service Refill Capacities

Cooling System
3gal (US)
Fuel Tank
11.4gal (US)
Hydraulic System
6.3gal (US)
Engine Oil
1.6gal (US)

Dimensions (Approximate) - Standard Lift

Cab Height
8.25ft
Ground Clearance
10in
Wheel Base
6.42ft
Overall Length - With Bucket*
15.4ft
Reach at Maximum Dump Height*
2.33ft
Dig Depth
5in
Maximum Dump Height*
7.75ft
Load Over Height
9.25ft
Hinge Pin at Maximum Height
10.08ft
Departure Angle - Degrees
30°
Overall Length - With Forks
16.83ft
Reach - Ground Level
2.5ft
Maximum Reach
4.33ft
Fork Depth Above Ground
3in
Fork Height at Maximum Reach
4.75ft
Maximum Fork Height
9.9ft
Fork Reach at Maximum Height
1.75ft
Turning Radius - Over Bucket*
12.75ft
Turning Radius - Inside Tire**
6ft
Width - Over Bucket*
5.83ft
Tire Gauge
4.33ft
Machine Width**
5.58ft
Articulation Angle
40°
Steering Angle
80°
Dump Angle at Maximum Height
40°
Note (1)
*Vary with bucket size.
Note (2)
**Vary with tire size.
Note (3)
Dimensions listed are based on a machine configured with cab, air conditioning, remote quick coupler, general purpose bucket or 1067 mm (42 in) forks, 75 kg (165 lb) operator, 33 × 15.5-16.5, 12 PR tires, without ride control, without precleaner.

Dimensions (Approximate) - High Lift

Cab Height
8.25ft
Ground Clearance
10in
Wheel Base
6.42ft
Overall Length - With Bucket*
16.03ft
Reach at Maximum Dump Height*
2.33ft
Dig Depth
6in
Maximum Dump Height*
8.16ft
Load Over Height
9.75ft
Hinge Pin at Maximum Height
10.58ft
Departure Angle - Degrees
30°
Overall Length - With Forks
17.25ft
Reach - Ground Level
2.9ft
Maximum Reach
4.66ft
Fork Depth Above Ground
2in
Fork Height at Maximum Reach
4.66ft
Maximum Fork Height
10.4ft
Fork Reach at Maximum Height
1.8ft
Turning Radius - Over Bucket*
13.4ft
Turning Radius - Inside Tire**
6ft
Width - Over Bucket*
5.83ft
Tire Gauge
4.33ft
Machine Width**
5.58ft
Articulation Angle
40°
Steering Angle
80°
Dump Angle at Maximum Height
40°
Note (1)
*Vary with bucket size.
Note (2)
**Vary with tire size.
Note (3)
Dimensions listed are based on a machine configured with cab, air conditioning, remote quick coupler, general purpose bucket or 1067 mm (42 in) forks, 75 kg (165 lb) operator, 33 × 15.5-16.5, 12 PR tires, without ride control, without precleaner.

Operating Specifications - Standard Lift

Tire Size
33 × 15.5-16.5, 12 PR
Rated Bucket Capacity
0.8yd³
Breakout Force
6294lbf
Operating Weight
9200lb
Rated Operating Load at Full Turn - Bucket***
2756lb
Straight Tipping Load - Bucket***
6415lb
Full Turn Static Tipping Load - Bucket (ISO 14397-1*)***
5516lb
Full Turn Static Tipping Load - Bucket (Rigid Tire**)***
5626lb
Rack Back - Transport Position
51°
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Firm and Level Ground, 500 mm [20 in] Load Center) (80% FTSTL)***
3393lb
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Rough Terrain, 500 mm [20 in] Load Center) (60% FTSTL)***
2544lb
Note (1)
*Full compliance to ISO 14397-1 (2007) Sections 1 thru 6, which requires 2% verification be-tween calculation and testing.
Note (2)
**Compliance to ISO 14397-1 (2007) Sections 1 thru 5.
Note (3)
***Manual quick coupler, precleaner hood.
Note (4)
Operating specifications shown are based on machine equipped with enclosed ROPS cab with air conditioning, remote quick coupler, 75 kg (165 lb) operator and general purpose bucket (GP), without ride control, without precleaner unless otherwise noted.

Operating Specifications - High Lift

Tire Size
33 × 15.5-16.5, 12 PR
Rated Bucket Capacity
0.8yd³
Breakout Force
6519lbf
Operating Weight
9231lb
Rated Operating Load at Full Turn - Bucket***
2553lb
Straight Tipping Load - Bucket***
5975lb
Full Turn Static Tipping Load - Bucket (ISO 14397-1*)***
5108lb
Full Turn Static Tipping Load - Bucket (Rigid Tire**)***
5238lb
Rack Back - Transport Position
51°
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Firm and Level Ground, 500 mm [20 in] Load Center) (80% FTSTL)***
3175lb
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Rough Terrain, 500 mm [20 in] Load Center) (60% FTSTL)***
2381lb
Note (1)
*Full compliance to ISO 14397-1 (2007) Sections 1 thru 6, which requires 2% verification be-tween calculation and testing.
Note (2)
**Compliance to ISO 14397-1 (2007) Sections 1 thru 5.
Note (3)
***Manual quick coupler, precleaner hood.
Note (4)
Operating specifications shown are based on machine equipped with enclosed ROPS cab with air conditioning, remote quick coupler, 75 kg (165 lb) operator and general purpose bucket (GP), without ride control, without precleaner unless otherwise noted.

Maximum Material Densities - General Purpose

Bucket Type
General Purpose
Rated Capacity
0.8yd³
Dump Height
93in
Maximum Material Density
3169lb/yd³
Bucket Width
70in
Note
Based on ISO 7546:1983 and rated operating loads at full turn and standard linkage.

Maximum Material Densities - Light Material

Bucket Type
Light Material
Rated Capacity
1.3yd³
Dump Height
88in
Maximum Material Density
1989lb/yd³
Bucket Width
74in
Note
Based on ISO 7546:1983 and rated operating loads at full turn and standard linkage.

Sound Levels

Interior Sound
80.8 dB(A)
Exterior Sound
99.8 dB(A)

Sustainability

Recyclability
95%

Work Made Easy

The 903 makes work easy with a 17% increase in horsepower with the all-new Cat C1.7 engine. This provides for improved performance when operating on grades and when using drive, steer, and lift simultaneously. The all-new optional hydraulic skid steer loader style coupler allows for faster and more efficient work tool changes while providing a viewing window that enables the operator to see the fork tips when using compact wheel loader style forks. Optional front and rear diff-lock can be activated on the fly, providing maximum traction in slick underfoot conditions.

Enjoy All Day Comfort

Operators will enjoy all day comfort with a multi-function joystick, spacious leg room, ergonomic pedal positioning, easy entry/exit, and optional speed sensitive ride control. The all-new seat provides optimal comfort, while featuring yellow adjustment touch points that make finding that perfect seat position easy. The minimal engine overhang provides excellent rear and corner visibility, making the 903 easy to operate in confined areas.

Configured for Success

Configure the 903 for success with new options such as engine and ground speed control, ideally suited for hydro-mechanical work such as using a broom. With the addition of a work tool electrical harness option, you can now run more tools than ever before. Two loader linkage options, standard and high lift, provide either improved capacity or improved lift height based on your application.

Simply Reliable

Fully opening rear hood allows easy access to the engine compartment featuring side-by-side coolers and transparent fuel/water separator with optional engine air pre-cleaner and radiator screen for high debris applications. Rear tie down locations under the machine allow for easy transport, while the service locations under the hood provide easy access for daily maintenance.

Standard Equipment:

Optional Equipment:

    Optional Equipment
    • Air conditioning/heater
    • Alternator, 90 amp for air conditioning
    • Antifreeze/coolant, extended life, protects to –50° C (–58° F)
    • Beacon ready
    • Cab:
      – Open
      – Enclosed
    • Differential lock, front and rear axles
    • Hydraulic quick coupler, skid steer loader compatible
    • Engine air precleaner
    • Engine block heater 120V (dealer installed)
    • Engine Speed Control (Throttle Lock)
    • Fenders:
      – Rear only
      – Front and rear
    • Ground Speed Control (Creeper Control)
    • Linkage:
      – Standard lift
      – High lift
    • Radiator debris screen
    • Radio Ready or AM/FM radio
    • Ride Control
    • Seats:
      – Mechanical suspension, vinyl with 51 mm (2 in) seat belt
      – Mechanical suspension, vinyl with 75 mm (3 in) seat belt
      – Mechanical suspension, fabric with 51 mm (2 in) seat belt
      – Mechanical suspension, fabric with 75 mm (3 in) seat belt
    • Tires:
      – 12-16.5 10PR
      – Flotation 33-15.5 × 16.5
      – Flexport 33 × 6 × 11
    • Working lights, front and rear:
      – Halogen
      – LED
    • Work Tool Electrical Harness
    Work Tools
    • For all work tool options, consult your Cat dealer.
